Equipment unrelated to the core of the process as input/output elements. It is capable of transmitting 1 megabyte in approximately 2 milliseconds, so its use in applications with strict times is very widespread. Its protocol is established as master-slave, which can be mono or multi. In mono master applications, only one element is master, the rest are slaves, their read cycles are shorter. The use of multi master is used for applications where the overall system can be divided into subsystems. Each master will have its own independent slaves from the rest. Profibus fms. It is a generic bus used for versatile communication in automation systems for control. Due to its functionality, it is normally applied in master-master communication. Increasingly, it is becoming obsolete due to ethernet profibuspa. It is used for e commerce photo editing the communication of the elements of the process in charge of working with analog signals such as humidity, temperature, light intensity or others. The use of this bus is mainly due to its reliability at the time of transmission, its security system, the possibility of being integrated into high-speed control systems and its relatively low cost. Through two simple wires, it performs communication, and for maintenance it allows the connection/disconnection of the equipment during operation. Connection between profibus dp and profibus pa. The process and sampling plant parts are connected with a dp/da coupler. To be able to continue communication and that both parties are united and the process develops dynamically. The purpose of this union is to make an easier installation by unifying the elements used and reducing hardware costs. We can differentiate between two possible situations when making the union of both networks. If the speed of profibus dp and profibus pa is similar. In this case only a media converter is used, the rest of the connection
Automation Systems and E Commerce Photo Editing content media
